B1 Fire Rated Nano PVDF Mirror Aluminum Composite Panel 1220x2440mm 4mm Silver ACP Cladding
| Place of Origin | Henan Province, China |
|---|---|
| Brand Name | Yongsheng |
| Certification | ISO 9001, SGS, CE, RoHS |
| Model Number | 1060，3003 |
| Minimum Order Quantity | 100 Pieces (about 300 sqm) |
| Price | USD 12-22 / Square Meter |
| Packaging Details | Mirror face to mirror face with interleaved PE film, seaworthy plywood crate with edge protectors |
| Delivery Time | 7-15 working days for stock colours, 15-25 working days for custom colours |
| Payment Terms | T/T,L/C,D/P,D/A |
| Supply Ability | 20000 Square Meters per Month |
Product Details
| Product Type | Mirror Aluminum Composite Panel (ACP) | Panel Thickness | 4mm (3mm, 5mm, 6mm Available) |
|---|---|---|---|
| Aluminum Skin Thickness | 0.21mm Front / 0.21mm Back | Aluminum Alloy | AA1100, AA3003, AA5005 |
| Core Material | Fire-retardant Mineral Core (FR) | Fire Rating | GB 8624 B1 / A2, ASTM E84 Class A |
| Surface Coating | Nano PVDF, 70% Fluorocarbon Resin | Coating Thickness | 25 Microns (2-coat) / 35 Microns (3-coat) |
| Reflectivity | 85% - 95% | Surface Gloss | 60% - 90% |
| Standard Size | 1220 X 2440mm | Maximum Width | 2000mm |
| Maximum Length | 6000mm | Peel Strength | 5 N/mm Minimum |
| Temperature Resistance | -50 To +150 Celsius | Colour Options | Silver, Gold, Champagne, Copper, Black, Rose |
| Warranty | 20 Years Exterior, 10 Years Colour Stability | Standards | GB/T 17748, ASTM E84, EN 13501-1 |
| Highlight | B1 fire rated mirror ACP,4mm silver PVDF aluminum panel,1220x2440mm mirror ACP cladding |
||
Product Description
B1 Fire Rated Nano PVDF Mirror Aluminum Composite Panel
This mirror aluminum composite panel is built for projects that need a true mirror finish plus a certified fire rating. A nano-PVDF fluorocarbon coating sits over the mirror-polished aluminum skin, so the reflective surface keeps its gloss through years of exterior exposure instead of hazing out after one or two seasons. The fire-retardant mineral core is rated B1 under GB 8624 and Class A under ASTM E84, which keeps the panel on the approved list for curtain walls, facade cladding and public interior projects.
Why buyers switch to this panel
- B1 / A2 fire rating - GB 8624 B1 and ASTM E84 Class A tested core, suitable for high-rise facades and public buildings where non-combustible cladding is mandatory.
- Nano PVDF fluorocarbon coating - 70% Kynar-grade PVDF resin with nano self-cleaning top layer, 20-year exterior colour and gloss warranty.
- 85-95% reflectivity - consistent mirror surface after precision rolling, grinding and polishing, batch to batch.
- Rigid but light - 4mm panel weighs about 5.5 kg/m2, roughly one tenth of solid stone, which cuts structural load and installation labour.
- Easy fabrication - scores, routs, bends and cuts with standard woodworking tooling; flat and stable after tension levelling.
- Full certification - ISO 9001, SGS, CE and RoHS reports supplied with every shipment.
Panel structure
- Protective PE film (removable, UV stable for 6 months outdoor storage)
- Nano PVDF coated mirror aluminum skin, 0.12-0.50mm
- Adhesive film, 2 layers
- Fire-retardant mineral core (FR grade) or LDPE core for interior use
- Back aluminum skin with anti-corrosion primer
Specifications
| Item | Value |
|---|---|
| Panel thickness | 3mm / 4mm / 5mm / 6mm |
| Aluminum skin thickness | 0.12mm - 0.50mm |
| Standard size | 1220 x 2440mm |
| Maximum width | 2000mm |
| Maximum length | 6000mm |
| Aluminum alloy | AA1100 / AA3003 / AA5005 |
| Core material | Fire-retardant mineral core (FR) / LDPE |
| Surface coating | Nano PVDF, 70% fluorocarbon resin |
| Coating thickness | 25 microns (2-coat) / 35 microns (3-coat) |
| Reflectivity | 85% - 95% |
| Surface gloss | 60% - 90% |
| Fire rating | GB 8624 B1 / A2; ASTM E84 Class A |
| Peel strength | 5 N/mm minimum |
| Temperature resistance | -50 °C to +150 °C |
| Colours | Silver, gold, champagne, copper, black, rose |
| Warranty | 20 years exterior, 10 years colour stability |
Applications
Curtain wall and facade cladding, building entrance and canopy, elevator lobby and cabin cladding, shopping mall and retail interior walls, exhibition and display backdrops, signage and light box faces, airport and metro station fit-out.
Packing and delivery
Panels are packed mirror face to mirror face with interleaved PE film, then fixed on seaworthy plywood crates with edge protectors. Standard loading is about 1800 sheets per 20ft container for 4mm x 1220 x 2440mm. Delivery is 7-15 working days for stock colours and 15-25 working days for custom colours.
Order notes
Tell us the panel thickness, aluminum skin thickness, colour, fire rating requirement and target project country. We will confirm the coating system and issue the test reports that local authorities ask for.
