1100 Aluminum Coil Industrial Grade Pure 1mm 2mm 3mm 5mm Mill Finish
| Place of Origin | Chian |
|---|---|
| Brand Name | Yongsheng |
| Certification | Yongsheng |
| Model Number | 1050 1060 1100 3003 3105 5052 6061 Aluminum Sheet Roll |
| Minimum Order Quantity | 1 ton |
| Packaging Details | Standard Seaworthy Wooden Pallet Packing |
| Delivery Time | 7-30 workdays |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, |
| Supply Ability | 5000 tons/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alloy/Grade | 1000 Series | Brand | Yongsheng Aluminum Industry Co., Ltd. |
|---|---|---|---|
| Thickness | 0.2-8.0mm | Temper | O-H112, Etc |
| Width | 20-2300mm | Process | CC/DC |
| Loading Port | Qingdao Port,Tianjin Port,Shanghai Port. | Standards | ASTM-B209,EN573-1,GB/T3880.1-2006 |
| Highlight | 2mm Aluminum Coil,3mm Aluminum Coil,1mm Aluminum Coil |
||
Product Description
1100 Aluminum Coil Industrial Grade Pure 1mm 2mm 3mm 5mm Mill Finish
1100 Aluminum Coil is manufactured from industrial pure aluminum with 99.00% aluminum content, offering exceptional performance for various industrial applications.
Key Features
- High Corrosion Resistance: Excellent performance in corrosive environments
- Excellent Electrical Conductivity: High electrical and thermal conductivity for electrical applications
- Good Formability: Easily molded into various shapes through press working techniques
- Not Heat Treatable: Cannot be strengthened by heat treatment but maintains strength through cold working
- Low Strength: Good ductility and plasticity with relatively low strength compared to other aluminum alloys
Mechanical Properties
- Tensile strength σb (MPa): ≥95
- Conditional yield strength σ0.2 (MPa): ≥50
- Elongation 50mm: ≥9
Specifications
| Aluminium Alloy | Thickness (mm) | Width (mm) | Temper |
|---|---|---|---|
| A1050,A1060,A1070,A1100 | 0.2-8.0 | 20-2300 | O,H12,H14,H16,H18,H22,H24,H26 |
| A3003,A3004,A3105 | 0.2-8.0 | 20-2300 | O,H12,H14,H16,H18,H22,H24,H26 |
| A5052,A5005,A5083,A5754 | 0.2-8.0 | 20-2300 | O,H12,H14,H34,H32,H36,H111,H112 |
| A6061,A6082,A6063 | 0.2-8.0 | 20-2300 | T4,T6,T651 |
Additional Specifications
- Material Process: CC AND DC
- Size: Custom production available per client requirements
- Surface: Mill finish, color coated (PVDF & PE), stucco embossed, bright polished, mirror, brush, perforated, thread plate corrugated, etc.
- Quality Standard: ASTM B209, EN573-1, etc.
- MOQ per size: 1 ton (samples available)
- Payment Terms: TT, LC at sight, DP, etc.
- Delivery Time: Within 7 days after receipt of LC or deposit
- Material Quality: Tension leveled, flat, free of defects (oil stain, marks, waves, dental scratches), A+++ quality, production process passed SGS and BV inspection
Applications
Construction Building, Decoration Curtain Wall Roofing, Mould, Lighting, curtain wall, ship building, Aircraft, Oil Tank Truck Body, and various industrial applications.
Packing
Standard export-worthy wooden pallets with approximately 2 tons/pallet. Pallet weight can be customized per client requirements.
